| Ink Type Compatibility |
Dye ink (50μm/60μm nozzles) and pigment ink (50μm/60μm nozzles) for standard industrial marking needs. |
Dye ink, pigment ink, and enhanced adhesion ink; optimized for rough surfaces like matte plastic and uncoated metal to reduce ink smudging. |
Dye ink (40μm/50μm/60μm nozzles), pigment ink (40μm/50μm/60μm nozzles). |
Extended to include special inks such as ultra-white pigment ink; suitable for dark-colored high-gloss substrates like black metal and deep blue plastic packaging. |
| Max Character Height |
0.8 - 5mm (40μm nozzle), 1 - 10mm (50μm/60μm nozzles). |
Consistent with CCS3000R; ink flow control is upgraded to maintain stable character height during long-term high-speed printing. |
0.8 - 5mm (40μm nozzle), 1 - 18mm (50μm nozzle), 2 - 10mm (60μm nozzle). |
Same as CCS3000L; adds adaptive height adjustment to automatically correct character size deviations caused by substrate vibration. |
| Core Printing Functions |
Supports 1 - 4 lines of text, 10 - digit number chain, barcodes (ITF, Code39, etc.), and 2D codes (DataMatrix, QR Code); can print custom LOGOs. |
Retains basic functions of CCS3000R; enhances 2D code error correction to ensure readability even with partial smudging; faster LOGO loading speed. |
Same basic printing functions as CCS3000R, with the same nozzle dot matrix editing space (max 26 vertical dots). |
On the basis of CCS3000L, adds real - time variable data printing (such as real - time production batch numbers) and supports faster switching between multi - group printing templates. |
| System & Connectivity |
Equipped with master - slave control (1 host controls 16 slaves); supports USB and Ethernet for data backup and real - time storage. |
Upgrades network stability with anti - interference Ethernet ports; enables remote fault diagnosis via the network to reduce downtime. |
Same master - slave control and interface configuration as CCS3000R. |
Adds cloud data synchronization; printing parameters and template files can be synced across multiple devices, suitable for factory - level centralized management. |
| Key Hardware Advantages |
New P - type nozzle with automatic sealing technology; built - in diaphragm pump for longer service life and stable ink composition. |
Upgrades nozzle anti - clogging technology; the cleaning cycle is extended by 30% compared with CCS3000R; the diaphragm pump is equipped with a wear - reminder function. |
Same P - type nozzle and built - in diaphragm pump as CCS3000R; the stainless steel cabinet has optimized heat dissipation. |
Reinforced nozzle protection cover; the pump system adds pressure stabilization module to adapt to large temperature fluctuations (0 - 40℃) in harsh workshops. |
| Target Application Industries |
Food, pharmaceuticals, and cosmetics; suitable for standard packaging marking such as date and batch number on plastic bottles and paper boxes. |
High - end food and pharmaceutical industries; meets strict marking requirements such as anti - counterfeiting and traceability in the medical device field. |
Widely used in food, building materials, daily chemicals, and printing industries; ideal for marking on wood, glass, and corrugated cardboard. |
Automotive parts, electronic components, and large - scale packaging lines; adapts to high - intensity 24/7 operation and complex substrate marking scenarios. |
| Reliability & Maintenance |
IP - rated for dusty and humid environments; low maintenance frequency with standard diaphragm pump and nozzle design. |
Lower solvent consumption than CCS3000R; self - inspection function for ink levels and nozzle status to alert users of issues in advance. |
Consistent with CCS3000R; optimized ink circulation reduces waste, lowering long - term operating costs. |
Enhanced dust and moisture resistance; the maintenance cycle is extended by 50% compared with CCS3000L; wearing parts (like pump seals) have longer service life and are easier to replace. |
