Videojet 15-S22KQ25-600, 15-S22KQ25-600 thermal transfer ribbon, Videojet TTR ribbon 22mm 600m, Videojet TTO wax ribbon, ultra narrow web coding ribbon, mini sachet thermal transfer ribbon.
Key Features
- Standard Parameters: Model 15-S22KQ25-600, pure black wax ink, 22mm×600m per roll, 10 rolls per export carton.
- Anti-static Lubricated Backcoat: Low-friction coating minimizes printhead abrasion, cuts maintenance costs and extends printhead service life.
- Optimized for Thin Light Substrates: Stable ink adhesion on ultra-thin PE, PP, composite film and lightweight single-use packaging.
- Smooth High-speed Operation: Supports line speed up to 800mm/s, uniform ink transfer without dot missing or ribbon snapping.
- Cost-saving Wax Formula: Low consumption design for small print areas, effectively reduces daily production material waste.
- Compact Ultra-narrow Width: 22mm slim size eliminates redundant ribbon usage compared to wider alternatives.
- Original Plug-and-play Fit: Direct replacement for original Videojet TTO printers, no machine parameter adjustment required.
Application Scenarios
Food & Snack Industry
- Mini seasoning sachets, single-sugar packets, tiny coffee cream pods
- Individual candy, chewing gum and mini nut small bags
- Portable single-serve sauce and condiment thin pouches
Pharmaceutical & Healthcare
- Tiny drug foil strips, mini oral medicine sachets
- Small auxiliary medical device thin packaging
Cosmetic & Personal Care
- Travel-sized mask, shampoo, lotion sample mini packs
- Single-use facial mask and skincare trial pouches
Light Narrow Web Production
- Low-height coding on vertical form fill seal (VFFS) narrow production lines
- Mini label, slim film batch & expiry date marking
FAQ
Q1: Which TTO printers support Videojet 15-S22KQ25-600 22×600 ribbon?
A1: It is fully compatible with all Videojet DataFlex and 6x00 series near-edge TTO printers as a genuine original replacement ribbon.
Q2: Is 15-S22KQ25-600 wax or wax-resin ribbon?
A2: It adopts pure wax ink formula, ideal for general thin film packaging with medium printing durability demands.
Q3: How many marks can one 600m ribbon roll print?
A3: For standard 8–12mm height date and LOT codes, one 600m roll can produce about 38,000–48,000 prints for continuous mass production.
Q4: What resistance do wax printed codes have?
A4: The printed text resists light water mist and minor friction. For heavy scratch, oil or long-term frozen cold chain storage, wax-resin grade ribbons are recommended.
Q5: What storage conditions are required for this TTR ribbon?
A5: Store in dry indoor environment with temperature 5°C–35°C and humidity 20%–80%. Keep away from direct sunlight and high heat; unopened shelf life reaches 12 months.
Q6: Can this ribbon work on non-Videojet thermal transfer printers?
A6: This ribbon is calibrated exclusively for original Videojet TTO equipment. Conduct ink sensitivity and core matching tests before bulk purchase for third-party printers.
Q7: How many ribbons are packed in one carton?
A7: Standard export carton includes 10 rolls of 15-S22KQ25-600 (22mm×600m) thermal transfer ribbons.
Q8: Why select 22mm narrow ribbon instead of wider sizes?
A8: 22mm ultra-narrow width fits mini single-use pouches with small print zones, avoiding unnecessary ribbon waste and lowering long-term coding material costs.
TIP：Our company is not an official authorized distributor of Videojet. The Videojet trademark used on this website is solely for indicating the product brand. All products sold are genuine original goods with legal sources. Pictures are for reference only.
