We provide comprehensive optimisation solutions for Videojet 6000 Series thermal transfer coding systems, encompassing ribbon matching and printhead accessory compatibility. For long-term operational equipment such as the 6210/6220/6230 models, we deliver critical component upgrades and system optimisation services. Our commitment is to help your equipment achieve exceptional print consistency, sustained stable performance, and significantly reduced overall operating costs within high-speed industrial environments.
Unlock the full potential of every Videojet thermal transfer printer through professional optimisation.
| Features | Videojet 6210 | Videojet 6220 | Videojet 6230 | Videojet 6320 | Videojet 6330 | Videojet 6420 | Videojet 6530 |
|---|---|---|---|---|---|---|---|
| Target Position | Economical entry - level digital solution | Cost - effective mid - low speed solution | Low - speed cost - effective digital transition model | Mid - speed cost - effective model for vertical form - fill - seal applications | Mid - high speed model with quality assurance for flexible packaging | High - speed wide - format high - output model | High - speed high - efficiency model for high - throughput operations |
| Max Printing Resolution | 300 dpi | 300 dpi | 300 dpi | 300 dpi | 300 dpi | Unspecified (refer to same series standard of 300 dpi) | Unspecified (refer to same series standard of 300 dpi) |
| Print Head Width | 32 mm | Unspecified (focus on high - precision small - area printing) | 32 mm | 32 mm, 53 mm | 32 mm, 53 mm | 53 mm, 107 mm | Unspecified (focus on high - speed operations) |
| Max Printing Speed | 125 packs/min | Unspecified (low - speed, optimized for continuous operation) | 150 packs/min; 500 mm/s (continuous mode) | 250 packs/min; 750 mm/s (both intermittent and continuous modes) | 250 packs/min; 750 mm/s | 400 packs/min | Unspecified (highlighted as high - speed model) |
| Max Ribbon Length | 700 meters | 400 meters | 700 meters | 1200 meters | Unspecified (supports easy ribbon replacement) | Unspecified (with ribbon saving functions) | Unspecified (designed for extended uptime) |
| Ribbon - related Features | Software - controlled ribbon drive; cross - printing for double ribbon utilization | Bidirectional ribbon drive; 75% reduction in ribbon change downtime | Bidirectional stepper motor for precise control; simple ribbon path | Cross and radial printing; 0.5mm printing pitch for high efficiency | Non - clutch ribbon drive; consistent tension control | Cross and radial printing; doubles ribbon utilization | Non - clutch ribbon drive to avoid ribbon damage |
| Operation Interface | 5.7 - inch color touchscreen with CLARiTY™ | Icon - based color touchscreen; WYSIWYG display | 5 - inch flat color QVGA CSTN touchscreen with CLARiTY™; Bluetooth control via Android phones | 8.4 - inch SVGA color touchscreen with CLARiTY™ | 800×600 TFT SVGA full - color LCD touchscreen | Unspecified (compatible with mainstream packaging control systems) | Unspecified (focus on reducing quality inspection time) |
| Core Functional Advantages | Compatible with both intermittent and continuous printing; suitable for users transitioning from analog equipment | 50% lower overall cost than traditional hot stamping machines; internal clock for real - time variable data printing | One controller can manage 4 printers; CLARiSOFT™ for error reduction | Master - slave control for up to 4 units; network browser remote control; rich barcode support | Equipped with iAssure™ coding quality assurance technology; compatible with CLARiTY software | 107mm wide format for ingredient lists and traceability info; ultra - fast horizontal form - fill - seal applications | Extends uptime; reduces quality inspection time and rework; optimized for high - efficiency production |
| Typical Applications | Low - speed flexible packaging in the food industry | Flexible packaging for pastries, cooked food, grains, etc. | Small - batch flexible packaging; suitable for analog - to - digital transition | Vertical form - fill - seal flexible packaging applications | Various flexible packaging; integrable with labeling machines from major manufacturers | High - volume flexible packaging; wide - format printing needs | High - throughput flexible packaging production lines requiring minimal downtime |
